Compact Reliable 12V 24V 48V 60V Charging Unit, 300W 750W 900W EV & Industrial Battery Charging Unit
Product Description
Compact Reliable 12V 24V 48V 60V Charging Unit
300W 750W 900W EV & Industrial Battery Charging Solutions
Friendly Reminder
The prices shown on this page are for reference only. The final transaction price will be recalculated and quoted based on your actual needs, purchase quantity, and market conditions. Online prices do not constitute a final transaction commitment.
Product Description
📊
Status Indication: Real-time status indication for charging in progress, full charge, fault conditions, etc.
🔌
Flexible Charging: Easy connection, suitable for factory sites, outdoor campsites, temporary work sites, enabling flexible charging.
🛡️
Full Protection: Overcurrent, overtemperature, short circuit, reverse connection, under voltage, and overvoltage protection with dynamic current regulation.
🏗️
Industrial Build: Integrated die-cast housing + potting sealing process. Waterproof, dustproof, and shock-resistant for harsh environments.
Specification - 300W Series
| Model | IPS-OB1215 | IPS-OB2410 | IPS-OB485 |
|---|---|---|---|
| Rated Output Voltage | 12V | 24V | 48V |
| Rated Output Current | 15A | 10A | 5A |
| Input power | ≤240W | ≤335W | ≤335W |
| IP Rating | IP55 | ||
| Size (MM) | L127*W123*H98 | ||
Specification - 750W Series
| Model | IPS-OB2425 | IPS-OB4815 |
|---|---|---|
| Rated Output Voltage | 24V | 48V |
| Rated Output Current | 25A | 15A |
| IP Rating | IP65 | |
| Cooling mode | Natural cooling | |
Internal Component Comparison
| Features | Our Integrated Module | Standard Manufacturers |
|---|---|---|
| Integration | High Integration Power Module | Multiple Separate Boards |
| Failure Points | Fewer potential failure points | High wiring complexity |
| Structure | Simpler & More Robust | Bulky & Complex |
Our battery chargers integrate most components into the power module, achieving a simpler structure and lower maintenance costs.
Hot Selling Models
IPS-OB1215
12VDC, 15A | 216W
IPS-OB4815
48VDC, 15A | 810W
IPS-OB6013
60VDC, 13A | 889W
IPS-OB2436
24VDC, 36A | 1036W
IPS-OB8010
80VDC, 10A | 900W
IPS-OB7225
72VDC, 25A | 2070W
Detail Gallery
Application Scope
Core Mission
We focus on the research and development, sales and service of DC to DC power supply modules, AC to DC rectifier modules, DC to AC inverters, and industrial chargers. We provide personalized, efficient, reliable and cost-effective power supply solutions for all industries. We are not only providing products but aim to give our customers the right power supply solution with optimized technical specifications.
Frequently Asked Questions
Q1: What battery types are these chargers compatible with?
A: Our chargers are designed to work with both Lead-Acid and Lithium battery types across various voltage ranges.
Q2: Do the units support international input voltages?
A: Yes, most of our series support single-phase input from 100V to 240V AC, and high-power units support 3-phase 380V input.
Q3: What is the environmental protection rating?
A: Depending on the model, the units offer IP55, IP65, or IP67 ratings, making them waterproof and dustproof for industrial use.
Q4: Are the output plugs and protocols customizable?
A: Yes, both output plugs and communication protocols can be customized according to your specific application requirements.
Q5: What safety protections are integrated into the charging unit?
A: Our units include overcurrent, overtemperature, short circuit, reverse connection, and overvoltage protections as standard features.
Q6: What is the typical conversion efficiency of these chargers?
A: The conversion efficiency ranges from 86% to over 92%, depending on the power series and model chosen.
