High-Efficiency Stable 12V 24V 48V Battery Charger, 300W 750W Communication & Laboratory Battery Charger
Product Description
High-Efficiency Stable 12V 24V 48V Battery Charger, 300W 750W Communication & Laboratory Battery Charger
⚠️ Friendly Reminder
Dear Customer: The prices shown on this page are for reference only. The final transaction price will be recalculated and quoted by our sales staff based on your actual needs, purchase quantity, and market conditions. The online prices are for your preliminary budget reference only and do not constitute a final transaction commitment. We always adhere to the principle of integrity and avoid price misrepresentation. Thank you for your understanding and trust.
Product Description
1
Real-time status indication for charging in progress, full charge, fault conditions, etc.
2
Easy connection, suitable for various scenarios such as factory sites, outdoor campsites, temporary work sites, enabling flexible charging.
3
Overcurrent, overtemperature, short circuit, reverse connection, under voltage, and overvoltage protection, with real-time temperature monitoring and dynamic current regulation.
4
Integrated die-cast housing + potting sealing process. Strong environmental adaptability with waterproof, dustproof, and shock-resistant features.
Technical Specifications
| Specifications | 300W Series | ||
|---|---|---|---|
| Model | IPS-OB1215 | IPS-OB2410 | IPS-OB485 |
| Input Current(Max) | ≤2.5A | ≤3.4A | ≤3.2A |
| Input power | ≤240W | ≤335W | ≤335W |
| Rated output voltage | 12V | 24V | 48V |
| Rated output current | 15A | 10A | 5A |
| Rated output power | 216W | 288W | 288W |
| DC output voltage | 6Vdc~16Vdc | 10Vdc~32Vdc | 10Vdc~60Vdc |
| Battery Type | Lead-Acid/Lithium | ||
| IP Rating | IP55 | ||
| Specifications | 750W Series | |
|---|---|---|
| Model | IPS-OB2425 | IPS-OB4815 |
| Input Current(Max) | ≤7.9A | ≤8.9A |
| Input power | ≤835W | ≤940W |
| Rated output voltage | 24V | 48V |
| Rated output current | 25A | 15A |
| Rated output power | 720W | 810W |
| IP Rating | IP65 | |
Internal Component Comparison
| Component | Our Solution | Manufacturers A | Manufacturers B |
|---|---|---|---|
| Power Module | Integrated Module | Power Module | Power Module |
| Main Power Switch | Simplified | Main Power Switch | Main Power Switch |
| Structure | Potting Sealing | Discrete Components | Discrete Components |
Our battery chargers integrate most components into the power module, thereby achieving a higher degree of integration, a simpler structure, fewer potential failure points, and lower costs.
Hot Selling Models
IPS-OB1215 Battery Charger
① AC IN: 1 phase 220VAC±15%
② DC OUT: 12VDC, 15A
③ Rated power: 216W
IPS-OB4815 Battery Charger
① AC IN: 1 phase 220VAC±15%
② DC OUT: 48VDC, 15A
③ Rated power: 810W
IPS-OB6013 Battery Charger
① AC IN: 1 phase 220VAC±15%
② DC OUT: 60VDC, 13A
③ Rated power: 889W
Details Images
Application Scope
About Our Solutions
We focus on the research and development, sales and service of D C to D C power supply module, A C to D C rectifier module, D C to A C inverter, A C power supply, D C power supply, L E D power supply, charger, rectifier system and other fields, to provide personalized, efficient, reliable and cost-effective power supply solutions for all industries. We are not only selling products. What we want to give our customers the right power supply solution, giving a better quotation solution with the right items. Together, let's make it much better.
Frequently Asked Questions
What battery types can these chargers support?
Our chargers are versatile and compatible with both Lead-Acid and Lithium battery types.
Are the chargers suitable for outdoor use?
Yes, they feature an integrated die-cast housing with potting sealing, offering IP55 to IP67 protection ratings (depending on the model), making them waterproof, dustproof, and shock-resistant.
Do the chargers include safety protections?
Absolutely. They come with overcurrent, overtemperature, short circuit, reverse connection, under voltage, and overvoltage protection, along with real-time temperature monitoring.
Can the output plugs be customized?
Yes, we provide customized output plugs and protocols to meet the specific requirements of your laboratory or industrial setup.
What is the energy conversion efficiency?
Our chargers offer high efficiency, typically ≥86% for the 300W series and reaching up to ≥92% for higher-wattage models.
What is the standard input voltage required?
Most models support a wide range of single-phase 100-240V AC input, while larger industrial models may require 3-phase 380V AC input.
