Waterproof IP67 12v 24v boost 56v Ev Fast Dc-dc Step-up Converter Battery Charger Used for Car Bus Vehicle Boat Motor 20a
Product Description
Waterproof IP67 12V 24V Boost 56V EV Fast DC-DC Step-Up Converter Battery Charger
High-performance power solution for car, bus, vehicle, boat, and motor applications.
High-performance power solution for car, bus, vehicle, boat, and motor applications.
✓ Technical Specifications
TypeNon-Isolate
Input Rate Volts12/24VDC
Input Volts Range12/24VDC Battery
Efficiency92%
Output Volts56VDC / 58VDC
Output Current20A
Rated Power1120W / 1160W
Waterproof RatingIP65 / IP67
Working Temp-40°c ~ +80°c
Ripple< 50mV
Machine Size220*130*50(MM)
CertificationsCE, RoHS
📷 Product Presentation
📏 Dimension & Details
? Frequently Asked Questions
Q1: What is the waterproof rating of this DC-DC converter?
A: This converter is designed with an IP67 rating (IP65/IP67 depending on specific housing), making it fully waterproof and dustproof, ideal for vehicle and marine environments.
Q2: Can it be used for both 12V and 24V battery systems?
A: Yes, it is compatible with both 12VDC and 24VDC input battery systems to provide a boosted output of 56V or 58V.
Q3: What is the energy efficiency of this device?
A: The converter operates at a high efficiency of 92%, ensuring minimal heat generation and maximum power delivery.
Q4: Does the device require active cooling like a fan?
A: No, it uses natural free air convection for cooling, which allows it to operate reliably in temperatures ranging from -40°C to +80°C.
Q5: Is this converter safe for sensitive electronic equipment?
A: Yes, it features stable voltage regulation (< 1%) and load regulation (< 2%) with a low ripple of less than 50mV to protect your equipment.
Q6: Are customized parameters supported?
A: Yes, customization is supported to meet specific voltage or current requirements for various industrial and automotive needs.
