Adjustable DC Power Supply Manufacturer Low Noise Precise High Resolution Programmable Control 0 50V 240A 12000W Lab Car Motor
Product Description
Adjustable DC Power Supply Manufacturer Low Noise Precise High Resolution Programmable Control 0-50V 240A 12000W Lab Car Motor
Friendly Reminder: The prices shown on this page are for reference only. The final transaction price will be recalculated and quoted based on your actual needs, purchase quantity, and market conditions.
💡 Product Description
1
Small size and light weight are suitable for work surface use and rack installation.
2
Using PWM modulation, the consumed power of the crystal module is low, high efficiency, and has more power. forced air cooling with a low-temperature coefficient.
3
Low noise and low ripple performance.
4
Using high gain amplifier circuit design, with good fast response characteristics.
5
Using a 4-bit high sampling rate, high-resolution voltage, and current digital display meter.
6
Built-in O.V.P. over-voltage and O.T.P. over-temperature protection circuit; reliable protection function.
7
Designed with load terminal voltage detection for accurate reading and precise control.
📋 Specification
| Model | IPS-ATDD50240 |
|---|---|
| AC Input | 3-phase 380VAC ±15%, 50Hz/60Hz |
| Output Range | 0-50VDC / 0-240A |
| Output Power | 12KW |
| Efficiency | 86% |
| Voltage Stabilization | ≤0.3%+10mV |
| Load Stabilization | ≤0.5%+30mV |
| Ripples and Noises | ≤0.5%+10mVrms |
| Display Accuracy | 4-digit Accuracy: ±1%+1 word |
| Protection | Built-in O.V.P. (Rated +5%), O.T.P. (85℃±5%), Current Limit |
| Setting | 10-turn precision potentiometer |
| Conditions | Indoor: 0℃~40℃, 10%~85%RH |
| Dimension / Weight | 132*430*500(MM) / 15KG |
| Options | Analog control (0-5/10VDC), RS485/RS232 Communication |
🔥 Hot Selling Models
IPS-ATDY2075
1 phase 110/220VAC
DC OUT: 0~20V, 75A
Max Power: 1500W
IPS-ATDY3050
1 phase 110/220VAC
DC OUT: 0~30V, 50A
Max Power: 1500W
IPS-ATDY4050
1 phase 110/220VAC
DC OUT: 0~40V, 50A
Max Power: 2000W
IPS-ATDY5060
1 phase 220VAC
DC OUT: 0~50V, 60A
Max Power: 3000W
IPS-ATDY12050
3-phase 380VAC
DC OUT: 0~120V, 50A
Max Power: 6000W
IPS-ATDY80150
3-phase 380VAC
DC OUT: 0~80V, 150A
Max Power: 12000W
📸 Details Images
🚀 Application Scope
📊 Model Series List (380VAC)
| IPS-ATDD Series (10KW - 20KW) | |||
|---|---|---|---|
| Model | Output Voltage | Output Current | Power |
| IPS-ATDD101000 | 10VDC | 1000A | 10000W |
| IPS-ATDD50200 | 50VDC | 200A | 10000W |
| IPS-ATDD121000 | 12VDC | 1000A | 12000W |
| IPS-ATDD50240 | 50VDC | 240A | 12000W |
| IPS-ATDD100120 | 100VDC | 120A | 12000W |
| IPS-ATDD151000 | 15VDC | 1000A | 15KW |
| IPS-ATDD100150 | 100VDC | 150A | 15KW |
| IPS-ATDD201250 | 20VDC | 1000A | 20KW |
| IPS-ATDD50500 | 50VDC | 400A | 20KW |
| IPS-ATDD100025 | 1000VDC | 20A | 20KW |
