Adjustable Output Prefabricated Current Function 0 20V 350A 7000W Stable DC Intelligent Terminal & Medical Equip Power Supply
Product Description
Adjustable Output DC Intelligent Power Supply
0-20V 350A 7000W Stable High-Power DC Supply for Terminal & Medical Equipment
Friendly Reminder: The prices shown on this page are for reference only. The final transaction price will be recalculated based on your actual needs, purchase quantity, and market conditions. These prices are for preliminary budget reference and do not constitute a final commitment.
Product Description & Features
1
Small size and light weight, suitable for both work surface use and rack installation.
2
PWM modulation ensures low power consumption of the crystal module, providing high efficiency and more power.
3
Well-designed electronic circuits with forced air cooling and heat treatment for a very low-temperature coefficient.
4
Ultra-low noise and low ripple output for sensitive applications.
5
High gain amplifier circuit design with excellent fast response characteristics.
6
High-resolution 4-bit digital display for precise voltage and current monitoring.
7
Built-in O.V.P. (over-voltage) and O.T.P. (over-temperature) protection circuits for maximum reliability.
8
Load terminal voltage detection for accurate reading and precise control of actual delivery voltage.
Technical Specifications
| Parameter | Details (Model: IPS-ATDD20350) |
|---|---|
| AC Input | 3-phase 380VAC ±15%, 50Hz/60Hz |
| Output Range | 0-20VDC / 0-350A |
| Output Power | 7000W |
| Efficiency | 86% |
| Voltage Stabilization | ≤0.3% + 10mV |
| Load Stabilization | ≤0.5% + 30mV |
| Ripples and Noises | ≤0.5% + 10mVrms |
| Display Accuracy | 4-digit Accuracy: ±1% + 1 word |
| Protection | Built-in O.V.P (Rated +5%), O.T.P (85℃±5%), Overload, Current Limit |
| Cooling Way | Forced fan cooling |
| Dimension / Weight | 460*430*88 (MM) / 12KG |
| Custom Options | Analog Control (0-5V/0-10V), Communication (RS485/RS232) |
Hot Selling Models
IPS-ATDY2075
0~20VDC, 75A, 1500W
IPS-ATDY3050
0~30VDC, 50A, 1500W
IPS-ATDY4050
0~40VDC, 50A, 2000W
IPS-ATDY5060
0~50VDC, 60A, 3000W
IPS-ATDY12050
0~120VDC, 50A, 6000W
IPS-ATDY80150
0~80VDC, 150A, 12000W
Details Images
Application Scope
Professional Power Solutions
We focus on the research, development, and service of DC to DC power supply modules, AC to DC rectifier modules, DC to AC inverters, and high-power DC power supplies. We provide personalized, efficient, reliable, and cost-effective power supply solutions for all industries. We don't just sell products; we provide the right engineering solutions to meet your specific requirements with the best items and value.
Frequently Asked Questions
Can I have a sample order?
Yes, sample orders are acceptable to test and check quality for initial cooperation.
What about the lead time?
Most models are in stock. The sample lead time after receiving payment is typically 1-3 working days.
How do you ship the goods and how long does it take?
We often ship by DHL, UPS, FedEx, or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping are also available as options.
How do I proceed with an order?
First, let us know your requirements or application. We will provide a quote based on your needs. Once samples are confirmed and a deposit is placed, we arrange production.
Do you offer a guarantee for the products?
Yes, we offer a 1-year warranty for all power supply products.
Is it possible to customize the product?
Yes, we support custom items including analog control (0-5V/0-10V) and communication interfaces like RS485 or RS232.
