Stable Volt Current Adjustable Output 40V 250A DC High Stability Industrial Lab R&D Precise Digital Control 10000W Power Supply
Product Description
Stable Volt Current Adjustable Output DC Power Supply
High Stability Industrial Lab R&D Precise Digital Control 10000W
💡 Friendly Reminder:
The prices shown are for reference only. Final transaction prices will be quoted based on your actual needs, purchase quantity, and market conditions.
Product Description
- Small size and light weight are suitable for work surface use and rack installation.
- Using PWM modulation, high efficiency, and low power consumption with a very low-temperature coefficient.
- Low noise and low ripple for precise laboratory and industrial applications.
- High gain amplifier circuit design with fast response characteristics.
- 4-bit high sampling rate, high-resolution voltage, and current digital display meter.
- Built-in O.V.P. (Over Voltage Protection) and O.T.P. (Over Temperature Protection) circuits.
- Load terminal voltage detection for accurate reading and precise control.
Technical Specifications
| Parameter | Details |
|---|---|
| Model | IPS-ATDD40250 |
| AC Input | 3-phase 380VAC ±15%, 50Hz/60Hz |
| Output Range | 0-40VDC / 0-250A |
| Output Power | 10KW |
| Efficiency | 86% |
| Voltage Stabilization | ≤0.3%+10mV |
| Load Stabilization | ≤0.5%+30mV |
| Display Accuracy | 4-digit Accuracy: ±1%+1 word |
| Protection | O.V.P., O.T.P., Overload, Current Limit |
| Cooling | Forced Fan Cooling |
| Dimensions | 132*430*500 (MM) |
| Weight | 15KG |
Hot Selling Models
IPS-ATDY2075
0~20VDC, 0~75A
Max Power: 1500W
IPS-ATDY3050
0~30VDC, 0~50A
Max Power: 1500W
IPS-ATDY4050
0~40VDC, 0~50A
Max Power: 2000W
IPS-ATDY5060
0~50VDC, 0~60A
Max Power: 3000W
IPS-ATDY12050
0~120VDC, 0~50A
Max Power: 6000W
IPS-ATDY80150
0~80VDC, 0~150A
Max Power: 12000W
Detailed Product Images
Application Scope
Series Overview
| Model | Voltage (VDC) | Current (A) | Power (W) |
|---|---|---|---|
| IPS-ATDD101000 | 10V | 1000A | 10000W |
| IPS-ATDD40250 | 40V | 250A | 10000W |
| IPS-ATDD100100 | 100V | 100A | 10000W |
| IPS-ATDD40025 | 400V | 25A | 10000W |
| IPS-ATDD100010 | 1000V | 10A | 10000W |
Our Solutions
We focus on the research, development, and service of DC to DC power supply modules, AC to DC rectifier modules, inverters, and high-precision DC power supplies. We provide personalized, efficient, and cost-effective power supply solutions for all industries. We don't just sell products; we provide the right engineering solutions to meet your specific requirements.
Frequently Asked Questions
Q1: Can I request a sample order for testing?
Yes, sample orders are welcome to test and check the quality for our first cooperation.
Q2: What is the typical lead time for orders?
Most models are in stock. For samples, the lead time is usually 1-3 working days after receiving payment.
Q3: Is there a Minimum Order Quantity (MOQ)?
We offer a low MOQ; even 1 piece for sample checking is available.
Q4: How are the products shipped and how long does it take?
We typically ship via DHL, UPS, FedEx, or TNT, taking 3-5 days. Airline and sea shipping are also optional for bulk orders.
Q5: Do you provide a warranty for your power supplies?
Yes, we offer a comprehensive 1-year warranty for all our power supply products.
Q6: Can the product be customized with a buyer's logo?
Yes. Please inform us formally before production and confirm the design based on our sample requirements.
