Factory Direct Sales 8000w 100-240v 60V 72V 96V 110V Ac Dc Industrial Switching Power Supply Manufacturer
Product Description
Factory Direct Sales 8000w 100-240v 60V 72V 96V 110V Ac Dc Industrial Switching Power Supply Manufacturer
★ Company Overview
We focus on the research and development, sales and service of D C to D C power supply module, A C to D C rectifier module, D C to A C inverter, A C power supply, D C power supply, L E D power supply, charger, rectifier system and other fields, to provide personalized, efficient, reliable and cost-effective power supply solutions for all industries.
We are not only selling products. What we want to give our customers the right power supply solution, giving a better quotation solution with the right items.
Our Advantages: We specialize in customizing switching Power Supply to meet your specific requirements. If you cannot find the right specification to meet your requirement, contact us now!
Our dedicated team endeavors to respond within one hour.
⚙ Product Features
- Adjustable with Compact size, light weight
- AC input 200-240VAC 50/60HZ (110VAC/120VAC support available)
- 100% full load burn-in test
- Protection: Short circuit / Over load / Over voltage
- Fixed switching frequency at 25KHz
- High efficiency, reliability quality, competitive cost
- 0-5Vdc / 0-10Vdc External control output (Optional)
- Extra adjustable potentiometer (Optional)
- Output voltage adjustable, output current be fixed (Optional)
📊 Technical Specifications
| Parameter | Details |
|---|---|
| Type | Switching Mode Power Supply |
| Model | IPS-SP60-113 |
| Input voltage | Single phase 200~240VAC |
| Input frequency | 50/60hz |
| DC Output Voltage | Based on model |
| Output Power | 8000W Max |
| Dimension | 351*210.8*148.5(mm) |
| Net / Gross Weight | 9.8KG / 14.6KG |
🔥 Hot Selling Models
IPS-PFC500-24 24VDC 500W
Input: 95-264VAC
Output: 24V, 20.83A
Input: 95-264VAC
Output: 24V, 20.83A
IPS-PFC500-48 48VDC 500W
Input: 95-264VAC
Output: 48V, 10.42A
Input: 95-264VAC
Output: 48V, 10.42A
IPS-PFC350-12 12VDC 350W
Input: 95-264VAC
Output: 12V, 29.17A
Input: 95-264VAC
Output: 12V, 29.17A
24VDC 1000W Series
Input: 110~240VAC
Output: 24VDC
Input: 110~240VAC
Output: 24VDC
24VDC 2000W Series
Input: 110~240VAC
Output: 24VDC
Input: 110~240VAC
Output: 24VDC
24VDC 3000W Series
Input: 110~240VAC
Output: 24VDC
Input: 110~240VAC
Output: 24VDC
📋 Model Selection (8000W Series)
| Model | Input Voltage | Output Voltage | Output Current |
|---|---|---|---|
| IPS-SP24-283 | 200-240VAC | 24VDC | 283A |
| IPS-SP48-141 | 200-240VAC | 48VDC | 141A |
| IPS-SP60-113 | 200-240VAC | 60VDC | 113A |
| IPS-SP110-61 | 200-240VAC | 110VDC | 61A |
| IPS-SP220-30 | 200-240VAC | 220VDC | 30A |
🛠 Customization Services
We specialize in customizing switching converters to meet your specific needs. Our products support customized input and output voltages and currents ranging from 1V to 1000V and 1A to 1000A.
We provide one-to-one customization services. Just tell us your needs and we will recommend the best solution for you. We are good at customizing various switching power supplies according to your usage scenarios and load information.
🏢 Application & Factory
❓ Frequently Asked Questions
What is the standard input voltage for these power supplies?
The standard input is 200-240VAC 50/60Hz. However, we also support 110VAC/120VAC inputs upon request.
Can the output voltage and current be adjusted?
Yes, we offer models with adjustable output voltage. External control (0-5V or 0-10V) and extra potentiometers are optional features.
What safety protections are included?
All units include built-in protection against short circuits, overloads, and overvoltage to ensure industrial-grade reliability.
Do you provide customized power solutions?
Yes, we specialize in customization. We can adjust parameters from 1V-1000V and 1A-1000A based on your specific load requirements.
Are the products tested before delivery?
Absolutely. Each unit undergoes a 100% full load burn-in test to guarantee quality and stable performance.
Is the technical consultation service free?
Yes, our professional sales engineers provide free one-to-one consultation and recommendation services for your power supply needs.
