IDEALPLUISING Energy-saving 5000W AC DC Smps Power Supply 24V 48V 60V 30A 50A 83.3A Medical Equipment Switching Power Supply
Product Description
Product Overview
Energy-saving 5000W AC DC Smps Power Supply 24V 48V 60V 30A 50A 83.3A Medical Equipment Switching Power Supply
Company Profile
We focus on the research and development, sales and service of DC to DC power supply module, AC to DC rectifier module, DC to AC inverter, AC power supply, DC power supply, LED power supply, charger, rectifier system and other fields, to provide personalized, efficient, reliable and cost-effective power supply solutions for all industries.
We are not only selling products. What we want to give our customers the right power supply solution, giving a better quotation solution with the right items.
🚀 Our Advantages:
We specialize in customizing switching Power Supply to meet your specific requirements. Please submit any inquiries to explore our capabilities further. If you cannot find the right specification to meet your requirement, contact us now!
We specialize in customizing switching Power Supply to meet your specific requirements. Please submit any inquiries to explore our capabilities further. If you cannot find the right specification to meet your requirement, contact us now!
Product Features
- Adjustable with Compact size, light weight
- AC input 200-240VAC 50/60HZ (110VAC/120VAC customizable)
- 100% full load burn-in test
- Protection: Short circuit / Over load / Over voltage
- Fixed switching frequency at 25KHz
- High efficiency, reliability quality, competitive cost
- 0-5Vdc / 0-10Vdc External control output (Optional)
- Extra adjustable potentiometer (Optional)
- Output voltage adjustable, output current fixed (Optional)
Technical Specifications
| Parameter | Details |
|---|---|
| Type | Switching Mode Power Supply |
| Model | IPS-SP60-83.3 |
| Input voltage | Single phase 200~240VAC |
| Input frequency | 50/60hz |
| DC Output Voltage | Based on model |
| Output Current | Based on model |
| Output Power | 5000W Max |
| Dimension | 356*216*80(mm) |
| Net Weight | 6.5KG |
Hot Selling Models List
IPS-PFC500-24 500W
Input: 95-264VAC | Output: 24VDC, 20.83A
IPS-PFC500-48 500W
Input: 95-264VAC | Output: 48VDC, 10.42A
IPS-PFC350-12 350W
Input: 95-264VAC | Output: 12VDC, 29.17A
IPS-PFC1000-24 1000W
Input: 110~240VAC | Output: 24VDC
IPS-PFC2000-24 2000W
Input: 110~240VAC | Output: 24VDC
IPS-PFC3000-24 3000W
Input: 110~240VAC | Output: 24VDC
Industrial Customization Options
We specialize in customizing switching converters to meet your specific needs. Our products support customized input and output voltages and currents ranging from 1V to 1000V and 1A to 1000A. We provide one-to-one customization services. Just tell us your needs and we will recommend the best solution for you.
Model Range Reference (400W - 10000W)
| Power Rating | Model Example | Input Voltage | Output Voltage | Output Current |
|---|---|---|---|---|
| 400W | IPS-SP12-33.3 | 110/220VAC | 0-12VDC | 33.3A |
| 600W | IPS-SP24-25 | 110/220VAC | 0-24VDC | 25A |
| 1000W | IPS-SP48-21 | 220-240VAC | 0-48VDC | 21A |
| 2000W | IPS-SP60-33.3 | 176-262VAC | 0-60VDC | 33.3A |
| 5000W | IPS-SP60-83.3 | 200-240VAC | 60VDC | 83.3A |
| 10000W | IPS-SP48-177 | 200-240VAC | 48VDC | 177A |
Product Dimensions & Multi-Angle Display
Application Scope & Factory Show
Frequently Asked Questions
Q1: Can the output voltage and current be customized?
A1: Yes, we provide professional customization services. We can customize output voltages from 1V to 1000V and currents from 1A to 1000A based on your load information.
Q2: What is the input voltage range for the 5000W model?
A2: The standard input is single-phase 200-240VAC. If you require 110VAC or other specific ranges, please specify your needs for a custom solution.
Q3: Does the power supply include safety protections?
A3: Yes, all units are equipped with short circuit, over-load, and over-voltage protections to ensure safe and reliable operation.
Q4: Are these power supplies tested before shipping?
A4: Absolutely. Every unit undergoes a 100% full load burn-in test to ensure stability and quality before it reaches the customer.
Q5: Can I control the output externally?
A5: Yes, we offer optional external control via 0-5Vdc or 0-10Vdc signals for flexible industrial integration.
Q6: What are the main applications for these SMPS units?
A6: They are widely used in medical equipment, industrial automation, CCTV systems, UV curing equipment, and lab testing environments.
