IDEALPLUSING Programmable DC Power Supply 480VDC 2400VDC 2A with RS232 Flexible Programming for Power Electronics Experiments
Product Description
ā ļø Friendly Reminder
Dear Customer: The prices shown on this page are for reference only. The final transaction price will be recalculated and quoted by our sales staff based on your actual needs, purchase quantity, and market conditions. The online prices are for your preliminary budget reference only and do not constitute a final transaction commitment.
Dear Customer: The prices shown on this page are for reference only. The final transaction price will be recalculated and quoted by our sales staff based on your actual needs, purchase quantity, and market conditions. The online prices are for your preliminary budget reference only and do not constitute a final transaction commitment.
- 1 Standard 2U/3U full-width dimensions; compact and lightweight design suitable for both benchtop use and rack mounting.
- 2 Clear and prominent 5-digit display; the LCD screen provides comprehensive information.
- 3 Dual encoders for voltage and current adjustment ensure convenient and user-friendly operation.
- 4 Programmable control over voltage, current, and time outputs.
- 5 Built-in memory supports the creation of up to 50 programmable steps for voltage, current, and time outputs.
- 6 Features RS-232/485 interfaces, supporting both Modbus-RTU and SCPI communication protocols.
- 7 Equipped with dedicated load-side voltage sensing terminals, enabling accurate measurement of the actual voltage at the load.
| Specifications | 2U/3U Chassis Series Details |
|---|---|
| Model | 3KW-8KW / 9KW-15KW |
| AC Input | Single Phase 220VĀ±10% / Three Phase AC380VĀ±10%; 50Hz/60Hz |
| Output Voltage | 0-2400VDC Rated Voltage |
| Output Current | 0-2A Rated Current |
| Output Power | 0-4800W Rated Power |
| Accuracy | Voltage/Current Regulation: ā¤Ā±0.1%FS |
| Ripple (rms) | ā¤0.1%FS+10mV |
| Display Mode | Color LCD Display (5-digit) |
| Protection | OVP, OCP, OTP (85ā threshold) |
| Interface | RS-485/RS-232 (Modbus & SCPI) |
| Cooling | Forced Air Cooling |
* All values are typical and may vary under different loads or temperature conditions.
IPS-DH10-6002
600VDC, 2A | 1200W
IPS-DH20-12003
1200VDC, 3A | 3600W
IPS-DH10-5001
500VDC, 1A | 500W
IPS-DH30-8500
8VDC, 500A | 4000W
IPS-DH10-10003
1000VDC, 3A | 3000W
IPS-DH20-8005
800VDC, 5A | 4000W
Versatile Applications: Used in capacitive load testing, inductive load testing, battery discharge testing, pulsed load testing, and motor drive testing applications.
| No | Model | Voltage | Current | Power | Resolution |
|---|---|---|---|---|---|
| 1 | IPS-DH20-32001.5 | 3200VDC | 1.5A | 4800W | 100mV/0.1mA |
| 2 | IPS-DH20-24002 | 2400VDC | 2A | 4800W | 100mV/0.1mA |
| 3 | IPS-DH20-12004 | 1200VDC | 4A | 4800W | 100mV/0.1mA |
| 4 | IPS-DH20-6008 | 600VDC | 8A | 4800W | 10mV/1mA |
| 5 | IPS-DH20-30016 | 300VDC | 16A | 4800W | 10mV/1mA |
1. Can this power supply be programmed for automated testing?
Yes, it supports up to 50 programmable steps for voltage, current, and time settings. It also includes RS-232 and RS-485 interfaces supporting Modbus-RTU and SCPI protocols for integration into automated systems.
2. What kind of display resolution does the unit provide?
The power supply features a high-precision 5-digit color LCD display, allowing for extremely accurate readbacks of voltage and current values.
3. Is this unit suitable for rack-mount installations?
Absolutely. The power supply follows standard 2U or 3U full-width dimensions, making it ideal for both laboratory benchtop use and professional rack mounting.
4. How does the unit handle high temperatures?
The device is equipped with forced air cooling and a built-in Over-Temperature Protection (OTP) system that triggers at 85āĀ±5% to protect internal components.
5. Can I customize the output voltage and current?
Yes, we provide customization options for various power ranges (3KW-15KW) and specific voltage/current requirements to suit your project needs.
6. What safety features are included?
The power supply includes configurable Over-Voltage Protection (OVP) and Over-Current Protection (OCP), ensuring the output turns off automatically if safety thresholds are exceeded.
