Factory Direct Sales 220V 380V 50/60hz Ac Industrial Inverter Frequency Converter 50KVA 60KVA Variable Frequency Power Supply
Product Description
Factory Direct Sales AC Industrial Inverter Frequency Converter 50KVA 60KVA Variable Frequency Power Supply
⚠️ Friendly Reminder
Dear Customer: The prices shown on this page are for reference only. The final transaction price will be recalculated and quoted by our sales staff based on your actual needs, purchase quantity, and market conditions. The online prices are for your preliminary budget reference only and do not constitute a final transaction commitment.
We always adhere to the principle of integrity and avoid price misrepresentation. Thank you for your understanding and trust.
Product Features
1
Complete isolation of input and output technology, safe and reliable power supply2
SPWM sine wave pulse width modulation technology for fast response and stable output3
IGBT high-frequency static inverter: small size, lightweight, and low noise4
Double-loop control mode for high precision and superior waveform quality5
Strong overload capacity and highly integrated module drive circuit6
Suitable for resistive, inductive, rectifier, and other complex loads7
Multiple protection: overheating, overcurrent, and short circuit8
Parameter memory function with 10-groups shortcut key operation9
Online adjustable voltage and frequency with real-time frequency changesMain Applications
| Home appliances | Motors | Power tools | Switching power supplies |
| Power adapters | UPS Systems | Communication Equipment | Photovoltaic (PV) |
| Lamps & Lighting | Electronic transformers | Distribution Systems | Industrial Power |
Series Specifications
FC61 Series (Single-Phase)
| Model | Capacity | Rated Power | Low-grade Current | High-grade Current | Weight |
|---|---|---|---|---|---|
| IPS-FC61005 | 0.5KVA | 0.4KW | 4.2A | 2.1A | 26KG |
| IPS-FC6101 | 1KVA | 0.8KW | 8.4A | 4.2A | 32KG |
| IPS-FC6102 | 2KVA | 1.6KW | 17A | 8.4A | 37KG |
| IPS-FC6105 | 5KVA | 4KW | 42A | 21A | 63KG |
| IPS-FC6115 | 15KVA | 12KW | 125A | 63A | 175KG |
FC62 Series (3-Phase Input, Single-Phase Output)
| Model | Capacity | Rated Power | Max Current (Low) | Max Current (High) | Dimension |
|---|---|---|---|---|---|
| IPS-FC6220 | 20KVA | 16KW | 168A | 84A | 58*74*52 CM |
| IPS-FC6260 | 60KVA | 48KW | 500A | 250A | 70*120*110CM |
| IPS-FC62100 | 100KVA | 80KW | 834A | 417A | 80*120*150CM |
| IPS-FC62200 | 200KVA | 160KW | 1667A | 834A | 100*150*160CM |
Hot Selling Models
IPS-FC6102 (2KVA / 1.6KW)
IPS-FC6250 (50KVA / 40KW)
IPS-FC6310 (10KVA / 8KW)
IPS-FC6330 (30KVA / 24KW)
IPS-FC68100 (100KVA / 80KW)
IPS-FC68200 (200KVA / 160KW)
Detailed Product Views
Application Scope & Customization
We specialize in customizing AC/DC/AC power supply to meet your specific requirements. With capacities ranging up to 2000KVA, our team ensures rapid response to all technical inquiries.
Frequently Asked Questions
Why are there both 50Hz and 60Hz power standards?
These standards originated historically. Europe and most of Asia adopted 50Hz, while the Americas and parts of Japan settled on 60Hz. A frequency converter is necessary to operate equipment designed for one standard on a power grid of another.
What types of loads can this frequency converter handle?
Our units are compatible with a wide range of loads, including resistive (heaters, lights), inductive (motors, compressors), and rectifier loads (switching power supplies, electronic equipment).
What is the benefit of the isolation technology used?
Complete isolation between input and output ensures that electrical noise or surges from the grid do not reach your sensitive equipment, providing a much safer and cleaner power supply.
Can I adjust the output frequency in real-time?
Yes, the power supply voltage and frequency can be adjusted online via the software interface or front panel, allowing for real-time testing and operation across a range of 40Hz to 499.9Hz.
What safety protections are built into the system?
The system includes comprehensive protection against overvoltage, overcurrent, overload, over-temperature, and short-circuit conditions, featuring an automatic jump protection and alarm device.
How high can the output capacity go?
While our standard models listed go up to 200KVA, we offer customization for industrial frequency converters with capacities reaching up to 2000KVA.
