IDEALPLUSING Hot Selling 60hz to 50hz Frequency Converter 2KVA 3KVA AC Power Supply
Product Description
Hot Selling 60Hz to 50Hz Frequency Converter 2KVA 3KVA AC Power Supply
Friendly Reminder
Dear Customer: The prices shown on this page are for reference only. The final transaction price will be recalculated and quoted based on your actual needs, purchase quantity, and market conditions. The online prices are for your preliminary budget reference only and do not constitute a final transaction commitment. We always adhere to the principle of integrity and avoid price misrepresentation. Thank you for your understanding and trust.
Product Features
1Complete isolation of input and output technology, safe and reliable power supply.
2SPWM sine wave pulse width modulation technology, with fast response speed and stable output.
3IGBT high-frequency static inverter, small size, lightweight, low noise, and high efficiency.
4Unique double-loop control mode of instantaneous and effective value for high precision and good waveform.
5Strong overload capacity, low loss, and high efficiency integrated module drive circuit.
6Suitable for resistive, inductive, rectifier, and other various loads.
7Multiple protection for overheating, overcurrent, and short circuit conditions.
8Parameter memory function with 10-group shortcut key operation.
9Real-time online adjustment for power supply voltage and frequency.
Application Fields
Home appliances
Photovoltaic
Motors
Lamps
Power tools
Electronic transformers
Switching power supplies
Electronic components
Power adapters
Low-voltage distribution
UPS
Power Systems
Information and communication
Other specialized industries
FC61 Series Specifications
| Model | IPS-FC61005 | IPS-FC6101 | IPS-FC6102 | IPS-FC6103 |
|---|---|---|---|---|
| Output Capacity (KVA) | 0.5KVA | 1KVA | 2KVA | 3KVA |
| Rated Power Output (KW) | 0.4KW | 0.8KW | 1.6KW | 2.4KW |
| Max Current (Low Range 150V) | 4.2A | 8.4A | 17A | 25A |
| Max Current (High Range 300V) | 2.1A | 4.2A | 8.4A | 12.5A |
Hot Selling Models
IPS-FC6102
1-Phase Input/Output 2KVA
IPS-FC6250
3-Phase Input/1-Phase Output 50KVA
IPS-FC6310
1-Phase Input/3-Phase Output 10KVA
IPS-FC6330
1-Phase Input/3-Phase Output 30KVA
IPS-FC68100
3-Phase Input/3-Phase Output 100KVA
IPS-FC68200
3-Phase Input/3-Phase Output 200KVA
Details Images
We specialize in customizing AC/DC/AC power supplies to meet your specific requirements. With customized frequency converters, our offerings range up to 2000KVA. Please submit any inquiries to explore our capabilities further. Our dedicated team endeavors to respond within one hour.
Frequently Asked Questions
Why are there 50Hz and 60Hz standards?
The frequency was selected arbitrarily when systems were stand-alone. Europe settled on 50Hz (AEG) while the US settled on 60Hz (Westinghouse). Today, Africa and most of Asia use 50Hz, while the Americas and parts of Japan use 60Hz. A static frequency converter is required to bridge these standards.
What is SPWM technology in frequency converters?
SPWM (Sinusoidal Pulse Width Modulation) is used to control the inverter output. It ensures the output waveform is a pure sine wave with low harmonic distortion, making it safe for sensitive electronic equipment.
Can these converters handle inductive loads like motors?
Yes, our frequency converters are designed to adapt to various loads, including resistive, inductive (like motors and compressors), and rectifier loads, thanks to the high-power IGBT modules.
What kind of protections are built into the device?
The systems include comprehensive protection against overvoltage, overcurrent, overload, over-temperature, and short-circuiting, complete with automatic jump protection and alarm devices.
Is the output voltage and frequency adjustable?
Yes, both voltage and frequency can be adjusted online. Frequency can be set between 40.0Hz and 499.9Hz via software, and voltage ranges from 0-150V or 0-300V depending on the range setting.
Are your products mobile-responsive for monitoring?
Our equipment is built with modern interface technology that allows for stable real-time parameter setting and memory storage, suitable for integrated industrial control systems.
